2017 Amp 16 - U-Brake - Gloss Orange


2017 Amp 16 - U-Brake - Gloss Orange

Technical Specifications
Top Tube Length:16.50"
Frame: Hi-tensile steel frame, HT(°): 74.5, CS ("): 11.25, SO ("): 7.00, BB ("): 9.30, ST (°): 71
Seat Clamp: Alloy
Fork: Hi-tensile steel, 2 piece
Handlebar: H: 7", W: 22.5", hi-tensile steel
Stem: Alloy top load - 40mm
Grips: Mushroom 90mm
Headset: Standard unsealed 1-1/8"
Brake: Wider pull U-Brake for 2.4 tire width
Brake Lever: Alloy for U-Brake
Gearing: 25/9
Cranks: Alloy 3 piece, forged 127mmm
Bottom Bracket: Sealed Euro BB 19mm
Sprocket: Steel, 25T
Pedals: Encore plastic 1/2", chromoly spindle
Chain: 410H
Front Hub: 3/8" unsealed 20H
Front Rim: Alloy single wall 20H
Front Tire: Innova 16 x 2.10
Rear Hub: 3/8", fully sealed cassette with 9T, 1 piece driver, 17mm axle nuts
Rear Rim: Alloy single wall 20H
Rear Tire: Innova 16 x 2.10
Seat: Padded seat w/rails for more adjustment
Seat Post:Alloy post w/steel guts
Pegs:N/A
Weight:20 lbs
