2016 Strutter DP Signature - Gloss Red
2016 Strutter DP Signature - Gloss Red
Ride like a pro with the Darcy Peters signature version of the Strutter, featuring a stronger frame and fork set up, built tough 3 piece tubular cranks and Odyssey Twisted PC pedals. Darcy's 21" frame set up along with big bars and top load stem make this bike the most spacious in the Encore 20" line. Added clearance in the frame and fork and a stronger brake make the Strutter fully set up for the fattest of aftermarket tires.
Keep down time to a minimum with low maintenance components like fully sealed rear cassette, integrated sealed headset, sealed Mid bottom bracket.
Technical Specifications
| Top Tube Length: | 21" |
| Frame: | Hi-tensile steel frame with chromoly head/down tube, HT(°): 74.5, CS ("): 13.25, SO ("): 8, BB ("): 11.5, ST (°): 71 |
| Seat Clamp: | Alloy |
| Fork: | Taper leg fork, chromoly steerer tube, integrated crown race |
| Handlebar: | H: 8.7", W: 29", hi-tensile steel |
| Stem: | Alloy "High Rise" top load - 50mm |
| Grips: | Mushroom 147mm |
| Headset: | Integrated sealed 1-1/8" |
| Brake: | Wider pull U-Brake for 2.4 tire width |
| Brake Lever: | Alloy for U-Brake |
| Gearing: | 25/9 |
| Cranks: | Chromoly 3 piece, tubular 175mm |
| Bottom Bracket: | Sealed MID BB 19mm |
| Sprocket: | Steel, 25T |
| Pedals: | Odyssey Twisted PC plastic 9/16", chromoly spindle |
| Chain: | 410H |
| Front Hub: | 3/8" unsealed alloy, 17mm axle nuts |
| Front Rim: | Alloy single wall 36H |
| Front Tire: | Innova 20 x 2.25 |
| Rear Hub: | 14mm, Fully sealed Cassette with 9T 1 piece driver w 17mm Axle nuts |
| Rear Rim: | Alloy single wall 36H |
| Rear Tire: | Innova 20 x 2.25 |
| Seat: | VELO 3mm padded leather cover |
| Seat Post: | Integrated with seat |
| Pegs: | N/A |
